Model T4B
Product Overview:
The Model T4B Spring Tester is a versatile high accuracy version that provides laboratory grade results. Rugged construction and high precision make this a durable device for accurate compression and optional tension testing of springs, spring forms, and resilient materials.
This tester utilizes the Model 3700/3701 display module that offers a real time display of load and height measurements along with data collection of several key spring testing parameters that can be displayed on the module, or output to a computer for generation of real-time load graphs, evaluation with third party SPC software, and data storage.
Key Benefits
- Pass-through load or height capture
- Automatic spring rate calculation
- Spring classification
- Direct mount platen for accurate load data
- Automatic load cell deflection compensation
- Simple operation
Application
- Compression
- Tension
- Squareness Under Load
- Lateral Load
Specifications:
- Operating Voltage
- 95 Vac to 250 Vac, 50/60 Hz
- Load Cell Range
- 20 kg (44 lb) up to 150 kg (330 lb)
- Load Cell Specifications
- -Total Error ± 0.1 % of rated output
- Height Specifications
- Daylight Opening – Maximum: 241 mm (9.5 in) option 304 mm (12 in)
- Stroke: 177 mm (7 in)
- Height Resolution: 0.025 mm (0.001 in)
